Ceramics , Filter Press , Sand Mill Air Diaphragm Pump
Pneumatic Diaphragm Pump Application and Advantage:
Pneumatic diaphragm pumps are operated with compressed air .
diaphragm pumps is suitable for pumping fluids with particles, and
various liquids, which are highly viscous, volatile, corrosive or
toxic, as well as colloids. The pump body is made of aluminum
alloys, cast iron or stainless steel. The diaphragm is made of high
quality rubber such as Nitrile rubber, chloronorgutta rubber,
fluoroine rubber. The diaphragm pumps are widely used in the
petroleum chemical, electronic, ceramic, food and textile
industries
Pneumatic Diaphragm Pump Parameters
| Item | Description | Unit | Reference Figure |
| 1 | Maximum air inlet pressure | Mpa | 0.83 |
| 2 | Maximum flow rate | L/Min | 192 |
| 3 | Maximum lift | M | 70 |
| 4 | Maximum outlet pressure | Mpa | 0.83 |
| 5 | Maximum particle size | mm | 3 |
| 6 | Weight | kg | 12.3 |
| 7 | Noise level | db | ＜70 |
About AODD Pneumatic Diaphragm Pump
If you're looking for a single pump that can be used in a wide
variety of applications, you want an air-operated double diaphragm
(AODD) pump. JBSL provides the most complete line of AODD pumps
available from one source. No other manufacturer offers more AODD
pumps – or more size and flow options – that meet every sanitary
standard, including FDA, USDA, 3A and EHEDG.
WHY AODD Pneumatic Diaphragm Pump
Air-operated double diaphragm (AODD) pumps offer a number of
advantages that make them perfect for an almost endless variety of
uses. AODD pumps:
- Can easily and efficiently handle anything from water to 90% solids
- Offer the ability to vary flow and discharge pressure up to 125 psi
with a simple adjustment of the air supply
- Enable one pump to be used for numerous applications, eliminating
the need for expensive motor drives and critical sizing
calculations
- Can pass even large, shear-sensitive solids without degradation or
heat buildup transferred to pumped medium
- Are able to run dry without damage to pump
- Can operate "on demand systems" without expensive pressure relief
and bypass accessories
- Will not froth or separate medium
- Are capable of pumping as slow as one gallon per minute
