    Double Air Driven Diaphragm Pump Membrane For Corrossive Liquid

    Double Air Driven Diaphragm Pump Membrane For Corrossive Liquid



    Air diaphragm pump(also know as a Membrane pump, air operated double diaphragm pump(AOOD)or pneumatic diaphragm pump)that uses a combination of the reciprocating action of a rubber,thermoplastic or diaphragm and suitable valves either side of the diaphragm (check valve,butterfly valves,flap valves,or any other form of shut-off valves) to pump a fluid.

    Product Description:

    Air Inlet

    1/4-18NPTF-1

    Fluid Outlet

    1-11-1/2NPTF-1,Rp1-11BSP

    Fluid Inlet

    1-11-1/2NPTF-1,Rp1-11BSP

    Max. Flow

    135L/Min

    Max. Head

    70M

    Max. Self-priming Lift (dry)

    4m

    Max. Air Pressure

    8.3bar

    Max. Particle Diameter

    3mm

    Max. Installation Dimension

    249.5×360.5×245mm

    Weight

    9.5kg

    Noise

    <80db

    Specifications

    Air Diaphragm Pump
    1. Non leakage
    2. Good self priming performance
    3. Convey all kinds of medium
    4. Material:Cast steel,Alu,SS,PP

    Application


    1. The pump can suck the peanut, pickles, tomato slurry, red sausage, chocolate, hops and syrup etc.
    2. The pump can suck the paint, pigment, glue and adhesive etc.
    3. The pump can suck various glazed slurries of tile, porcelain, brick and chinaware etc.
    4. The pump can suck various grinding materials, corrosive agent and clean the oil dirt etc.
    5. The pump can suck various toxin and flammable or volatility liquid etc.
    6. The pump can suck various wedge water, cement slurry and mortar etc.
    7. The pump can suck various strong acid, alkali and corrosive liquid etc.
    8. It can be used as a front-step tranmission device of the solid and liquid separation equipment.
