Ceramics Pneumatic Double Diaphragm Pump , Air Operated Double
Diaphragm Pump
Pneumatic Double Diaphragm Pump Introduction
Pneumatic Double Diaphragm Pump (also know as a Membrane pump, air operated double diaphragm pump(AOOD) or pneumatic diaphragm pump)that uses a combination of the reciprocating action of a
rubber,thermoplastic or diaphragm and suitable valves either side
of the diaphragm (check valve,butterfly valves,flap valves,or any
other form of shut-off valves) to pump a fluid.
Pneumatic Double Diaphragm Pump Parameters
| Item | Description | Unit | Reference Figure |
| 1 | Maximum air inlet pressure | Mpa | 0.83 |
| 2 | Maximum flow rate | L/Min | 192 |
| 3 | Maximum lift | M | 70 |
| 4 | Maximum outlet pressure | Mpa | 0.83 |
| 5 | Maximum particle size | mm | 3 |
| 6 | Weight | kg | 12.3 |
| 7 | Noise level | db | ＜70 |
Pneumatic Double Diaphragm Pump Specifications
1. Non leakage
2. Good self priming performance
3. Convey all kinds of medium
Pneumatic Double Diaphragm Pump Application:
Pneumatic Double Diaphragm Pump is widely applied in waste water treatment, chemical industry,
petrochemical
industry, painting, ceramics, environmental protection, printing
and dyeing, etc. to deal with all kinds of
corrosive, volatile, flammable, poisonous fluids with particles and
high viscosity.
Pneumatic Double Diaphragm Pump Maintenance
- Some BSK parts are marked as "wearing parts", which can conduce to
quick service and downtime reduction.
- Service kits are divided to service two separate diaphragm pump
functions: 1. AIR SECTION, 2. FLUID SECTION. The FLUID SEC -TION is
divided further to match typical part MATERIAL OPTIONS.
- Provide a clean work surface to protect sensitive internal moving
parts from contamination from dirt and foreign matter during
service disassembly and reassembly.
- Keep good records of service activity and include pump in preven
-tive maintenance program.
- Before disassembling, empty captured material in the outlet man
-ifold by turning the pump upside down to drain material from the
pump.
Packing Details
