    316 Stainless Steel Diaphragm Pump For Hydrochloric Acid

    Ask Lasest Price
    Brand Name : JBSL
    Model Number : 80SS
    Certification : CE EX ISO EAC
    Payment Terms : L/C, D/P, T/T
    Supply Ability : 10000/mon
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    316 Stainless Steel Diaphragm Pump For Hydrochloric Acid

    Corrosion Protection Material Air Dipahragm Pump For Hydrochloric Acid, Sulfuric Acid
    Overview
    Quick Details
    Brand Name:
    JBSL
    Model Number:
    A80SS-STT-C
    Place of Origin:
    Guangdong, China
    Pressure:
    8.3 Bar
    Structure:
    Diaphragm Pump
    Air Inlet:
    3/4-14NPTF-1
    Liquid Outlet:
    3" Flange
    Liquid Inlet:
    3" Flange
    Max Flow:
    903L/Min
    Max Head:
    70M/Water
    Max Self-Priming Lift(Dry):
    4.5M
    Max Air Pressure:
    8.3Bar
    Max Particle Diameter:
    9mm
    Max Installation Dimension:
    542*724*403cm
    Weight:
    95KG
    Power:
    Pneumatic
    Usage:
    Air Pump
    Standard or Nonstandard:
    Standard
    Fuel:
    Air
    Application:
    Liquid pumping
    Microscope Theory:
    Air operated diaphragm pump
    Supply Ability
    Supply Ability:
    2000 Piece/Pieces per Month
    Packaging & Delivery
    Packaging Details
    1PCS/PP bag; 1 manual; 1 promotion shoou out; 1 Box
    Port
    Guangzhou
    Lead Time :
    7-20days
    Model No.Pipe SizeAir side/
    Fluid side Material
    Seat MaterialDiaphragm/Ball
    Material
    A80SS-STT-C3’inch316#Stainless Steel
    (SS)
    316#Stainless Steel
    (SS)
    PTFE
    Product Description

    Pneumatic diaphragm pump is a new transport machinery , is currently one of the most

    innovative pump . Using compressed gas as a power source for a variety of corrosive liquid ,

    with particles of liquid , high viscosity , volatile, flammable, poisonous liquid can be pumped

    optical exhaustion . There are four pneumatic diaphragm material: plastic , aluminum, cast iron ,

    stainless steel. Pneumatic diaphragm pumps were used nitrile
    rubber,neoprene , Viton , , depending on the liquid medium , poly ethylene forty-six .

    To meet the needs of different users . Placed in a variety of special occasions , for

    pumping a variety of conventional pumps can not pump the media , have achieved satisfactory results.

    Product Application
    *Chemical Factory

    Material handling or removable barrels material

    ( instead of drum pumps ),applicable to concentrated

    sulfuric acid, nitric acid and other strong oxidizing

    materials.

    *Pharmaceutical factoryMaterial handling or removable barrels material
    ( instead of drum pumps )
    *Biological technology factoryPumping animal blood for refining
    *New energy plant/
    multi crystalline silicon plant
    Pumping polysilicon raw material for solar
    *Commodity FactoryPumping perfume / fragrance / dairy mixture
    *Pressure filterPlate-and-frame type filter press, for filter polluted water
    and separate moisture material.
    *Moving baggy filterIndustrial wastewater filtration or chemical material separation
